Encrypt User Data at Rest: Envelope Encryption and Key Rotation

Turning on disk encryption doesn't protect you from a leaked database dump or a SQL injection, because the database decrypts everything for any query it serves. This post builds field-level envelope encryption in Python, rotates the master key without downtime, makes an encrypted column searchable with a blind index, and does the KMS cost arithmetic from the published AWS and Google Cloud prices.

Everything was run on one Windows laptop (Python 3.12.10, cryptography 50.0.2, SQLite). I haven't operated this at production scale, so I give per-operation numbers I measured and label extrapolations as arithmetic. All the scripts are shown below in full, so you can reproduce every printed output.

Which layer encrypts which field

There are three layers, and they defend against different things:

Layer Stops Doesn't stop
Disk / volume encryption stolen disk, discarded hardware anyone who can query the database
Database TDE or managed-service encryption stolen backups, snapshots SQL injection, a leaked app credential, a dump taken through the DB
Field-level (application) encryption all of the above, plus DB-level read access a compromised app server (it holds keys at runtime)

A decision rule you can copy:

Field Example columns Layer
Harmful in a breach, never searched ssn, passport_no, oauth_refresh_token, diagnosis Field-level envelope encryption
Harmful in a breach, looked up by equality email, phone Field-level + blind index
Not sensitive alone, or needed for LIKE/sorting/joins display_name, created_at, country Disk/TDE only

Field-level encryption costs you SQL: you can't LIKE, sort or index ciphertext.

Where does the KEK live at runtime? Pick one:

  • KMS call per value if you decrypt a few values per request and you need revoking IAM access to stop an attacker immediately. Every read pays a network round trip.
  • KEK cached in process memory, TTL 5 minutes if you decrypt many values per request. The TTL is my choice, not a documented value. As arithmetic: one process unwraps at most 12 times an hour per KEK instead of once per read. The threat you accept: someone who can read your process memory gets the raw KEK for up to the TTL, not just the plaintexts they can already reach, and revoking IAM access takes up to 5 minutes to bite.

How to encrypt user data at rest in Python

The idea, as AWS describes it: encrypt data with a data key (DEK), then encrypt the DEK under a key-encryption key (KEK). Store the wrapped DEK next to the data. Google's guidance adds the rules I followed: generate DEKs locally, use a new DEK on every write, and never share a DEK between two users.

envelope.py (it also holds the rotation helper used later):

import os
from cryptography.hazmat.primitives.ciphers.aead import AESGCM

class Keyring:
    """KEKs by id. In production these live in a KMS; here they're in memory."""
    def __init__(self):
        self.keks, self.current = {}, None
    def add(self, kid):
        self.keks[kid] = AESGCM.generate_key(256)
        self.current = kid

def _wrap(kr, kid, dek, aad):
    n = os.urandom(12)
    return n, AESGCM(kr.keks[kid]).encrypt(n, dek, aad + kid.encode())

def _unwrap(kr, env, aad):
    return AESGCM(kr.keks[env["kek"]]).decrypt(env["n2"], env["wdek"], aad + env["kek"].encode())

def encrypt_field(kr, plaintext: bytes, aad: bytes):
    dek = AESGCM.generate_key(256)                  # fresh DEK per value
    n1 = os.urandom(12)
    n2, wdek = _wrap(kr, kr.current, dek, aad)
    return {"kek": kr.current, "n1": n1, "ct": AESGCM(dek).encrypt(n1, plaintext, aad),
            "n2": n2, "wdek": wdek}

def decrypt_field(kr, env, aad: bytes):
    return AESGCM(_unwrap(kr, env, aad)).decrypt(env["n1"], env["ct"], aad)

def rewrap(kr, env, aad: bytes):
    """Move the DEK to the current KEK. The payload ciphertext is untouched."""
    if env["kek"] == kr.current:
        return env
    n2, wdek = _wrap(kr, kr.current, _unwrap(kr, env, aad), aad)
    return {**env, "kek": kr.current, "n2": n2, "wdek": wdek}

if __name__ == "__main__":
    kr = Keyring(); kr.add("kek-1")
    aad = b"users.ssn:42"                           # table.column:row id
    env = encrypt_field(kr, b"078-05-1120", aad)
    print("roundtrip:", decrypt_field(kr, env, aad))
    try: decrypt_field(kr, env, b"users.ssn:43")    # same ciphertext pasted into row 43
    except Exception as e: print("row-swap ->", type(e).
