Code Quality Metrics That Matter: Complexity and Churn (Flask Case Study)

The decision rule, up front: gate cyclomatic complexity (CCN) at 15 on changed files in CI, report churn monthly, and review the top five complexity-times-relative-churn hotspots by hand. Below is a runnable analysis of Flask that produces the hotspot list, what the research does and doesn't support, and a CI step you can paste in. If you want the pipeline basics first, see our CI/CD pipelines guide; for the human side, code quality in production.

Which code quality metrics to measure first

Versions: radon 6.0.1, lizard 1.24.1, pandas 3.0.6, Python 3.12.10, Flask at commit d73fa1cd (2026-09-08). You need a full clone; churn comes from history. All commands below were run on Windows 11 in Git Bash, so radon and lizard print paths with backslashes (flask\src\flask\app.py). The CI step normalises them; on an ubuntu runner they are already forward slashes.

python -m venv v && ./v/bin/pip install radon lizard pandas   # Windows: v\Scripts\pip
git clone https://github.com/pallets/flask.git

Radon is Python-only. Lizard supports 29 languages, so use it if your backend isn't Python.

Cyclomatic complexity: how to measure it in Python

Cyclomatic complexity is, per radon's docs, the number of decisions in a block plus one. Radon ranks it A (1-5) through F (41+) (ranks).

$ radon cc flask/src/flask -n C -s
flask\src\flask\app.py
    M 1227:4 Flask.make_response - C (16)
    M 1105:4 Flask.url_for - C (13)
    M 633:4 Flask.run - C (12)
flask\src\flask\cli.py
    F 1061:0 routes_command - C (18)
    F 120:0 find_app_by_string - C (14)
    F 698:0 load_dotenv - C (13)
    F 41:0 find_best_app - C (12)
flask\src\flask\debughelpers.py
    F 124:0 explain_template_loading_attempts - C (13)
flask\src\flask\sansio\app.py
    M 605:4 App.add_url_rule - C (13)
flask\src\flask\sansio\blueprints.py
    M 273:4 Blueprint.register - D (23)

$ radon cc flask/src/flask -a | tail -2
411 blocks (classes, functions, methods) analyzed.
Average complexity: A (2.727493917274939)

$ lizard flask/src/flask -C 15 -w
flask/src/flask\sansio\blueprints.py:273: warning: register has 61 NLOC, 23 CCN, 470 token, 3 PARAM, 105 length, 0 ND
flask/src/flask\app.py:1227: warning: make_response has 65 NLOC, 16 CCN, 338 token, 2 PARAM, 141 length, 0 ND
flask/src/flask\cli.py:1061: warning: routes_command has 35 NLOC, 18 CCN, 305 token, 2 PARAM, 47 length, 0 ND

10 of 411 blocks score C or worse under radon (C starts at 11); lizard's default threshold of 15 flags 3. The threshold decides how many warnings you get, so pick one and keep it. The average (A) says nothing; read the tail.

Code churn analysis with git log

Churn is how much a file changes. analyze.py counts non-merge commits and added+deleted lines per file with git log --numstat --no-renames, and joins them to lizard's per-file CCN. Derived columns: rel_churn (changed lines divided by current NLOC, a rough relative churn) and fix_ratio (share of a file's commits whose subject matches fix/bug/regression, a rough proxy). The hotspot score is percentile rank of total CCN times percentile rank of relative churn, my own crude heuristic rather than a standard. I use relative churn because Nagappan and Ball found absolute churn weak (details below). The script also prints the absolute-commits variant (hot_abs) so you can compare. The hotspot idea comes from Adam Tornhill.

"""usage: python analyze.py REPO_PATH SINCE [SUBDIR]"""
import collections, re, subprocess, sys
import lizard
import pandas as pd
from radon.complexity import cc_visit

repo, since = sys.argv[1], sys.argv[2]
subdir = sys.argv[3] if len(sys.argv) > 3 else "."
FIX = re.compile(r"\b(fix|fixes|fixed|bug|regression)\b", re.I)

def git(*args):
    r = subprocess.run(["git", "-C", repo, *args], capture_output=True,
                       text=True, encoding="utf-8", check=True)
    return r.stdout

# churn: one pass over history; --no-renames keeps paths real
log = git("log", f"--since={since}", "--no-merges", "--no-renames",
          "--numstat", "--format=@@%H|%s", "--", subdir)
churn = collections.defaultdict(lambda: dict(commits=0, added=0, deleted=0, fix_commits=0))
commits, is_fix = 0, False
for line in log.splitlines():
    if line.startswith("@@"):
        commits += 1
        is_fix = bool(FIX.search(line.split("|", 1)[1]))
        continue
    parts = line.split("\t")
    if len(parts) == 3 and parts[0].isdigit() and parts[2].endswith(".py"):
        c = churn[parts[2]]
        c["commits"] += 1
        c["added"] += int(parts[0]); c["deleted"] += int(parts[1])
        c["fix_commits"] += is_fix

# complexity: current working tree
rows = []
for path, c in churn.items():
    try:
        with open(f"{repo}/{path}", encoding="utf-8") as fh:
            src = fh.read()
    except FileNotFoundError:
        continue  # deleted since; nothing to join
    info = lizard.analyze_file.analyze_source_code(path, src)
    ccn = [f.cyclomatic_complexity for f in info.function_list]
    rows.append(dict(file=path.removeprefix(subdir.rstrip("/") + "/"), nloc=info.nloc,
                     max_ccn=max(ccn, default=0), sum_ccn=sum(ccn),
                     radon_max=max((b.
